P-PTH2-E This updated full-color, 20 x 28-inch (51 x 71 cm) wall poster visually defines minimum/maximum Class 2 through-hole solder joint acceptability requirements from Revision E of the IPC-A-610 and J-STD-001 industry standards. Containing high-quality computer graphics, this poster depicts complex through-hole solder joint requirements so clearly, that all operators and inspectors can easily understand and apply this important criteria.
Bring technically accurate, industry-consensus acceptability standards to your training room or inspection area with this highly visual learning and reference tool. This product includes one poster, for Class 2. (Also available in a Class 3 version, part number: P-PTH3-E
Note: Free Review is an Adobe Acrobat ".pdf" download. Left-click on Free Review button to launch PDF viewer, or right-click and choose "Save Target As," or the equivalent, to download file (0.3MB). Please be sure that your pop-up blocker is turned off.
